SUNSHINE P1 Pro Intelligent Stabilized Voltage Power Meter Repair Equipment Voltage Stabilization Short Circuit Fault Detection Tool - EU Plug
Rate: ( 0 reviews ) views: 62
Item No.: 661601012A Ships in 1 - 3 days MOQ: 1
| 1+ units | 2+ units | 5+ units | 10+ units | 20+ units |
| $121.65 | $120.66 | $119.67 | $117.66 | $116.67 |
Contact Sales Manager
- [email protected]
- Ipartsexpert - Ada Shi
+86 - 18620397679
Specifications
- Gross Weight :1.792kg
- Volume Weight :0.376kg
- Length :20.000cm
- Width :12.000cm
- Height :7.000cm
- Weight :1.600kg
- EAN :
- With Retail Packaging :Yes
Product Description
SUNSHINE P1 Pro Intelligent Stabilized Voltage Power Meter Repair Equipment Voltage Stabilization Short Circuit Fault Detection Tool - EU Plug
- Supports precision welding of electronic components, battery plate replacement, lithium battery nickel sheets, etc.; the first/second pulse duration can be customized
- Solve the short-circuit fault repair of mobile phones and various electronic devices, quickly switch three-way voltage, and support free adjustment of current and voltage
- Supports PD/QC fast charging protocol, real-time detection of fast charging voltage and current, more powerful functions
- Supports iP/Android battery protocol, one-click power-on test of the motherboardmaking maintenance more convenient
- Current size and range are automatically switched, current sampling accuracy is 0.1mA, and waveform display is clearer and more convenient
- It can be used in many fields such as burn-in, battery spot welding, battery start-up, QC fast charging, PD fast charging, waveform display, remote upgrade, comprehensive voltage stabilization output, etc.
Specifications:
| Model | P1 Pro |
| Product | Intelligent regulated power meter |
| Size | 68*120*195mm |
| Weight | 1105g |
| Buming Cord Length | 560mm |
| Spot Welding Line Length | 675mm |
| Power Cord Length | 1480mm |
| Input Voltage | 100V-230V 50/60Hz |
| Total Output Power | 250W |
| Mains Voltage | 0~28V |
| Main Supply Current | 0~20A |
| Fast Charge | PD/QC3.0 |
| Power Supply Output Voltage at Startup | 2-5.2V |
| Power Supply Output Current at Startup | 0.45-6A |
| Display Resolution | Voltage 0.01V Current 0.001A |
| Working Conditions (Temperature) | 0~40℃ |
| Warking Conditions (Relative Humidity) | 80% |
| Storage Conditions (Temperature) | -10~70℃ |
| Storage Conditions (Relative Humidity) | 35%~45% |
Compatible with:
- Universal
Package included:
- 1 x Host
- 1 x Power Cord
- 1 x Spot Welding Wire
- 1 x Burming Wire
- 1 x English and Chinese Use Manual
