RF4 RF-7050TVD2+4KC1PRO+M156 4K Stereo Microscope Trinocular Zoom 7-50X with 15.6inch HD Display for PCB IC Repair
Rate: ( 0 reviews ) views: 62
Item No.: 6616001985A Ships in 1 - 3 days MOQ: 1
| 1+ units | 2+ units | 4+ units | 5+ units | 10+ units | 20+ units |
| $544.78 | $540.16 | $535.55 | $530.93 | $526.31 | $521.70 |
Contact Sales Manager
- [email protected]
- Ipartsexpert - Ada Shi
+86 - 18620397679
Specifications
- Brand :RF4
- Color :As Shown
- Gross Weight :9.520kg
- Volume Weight :12.983kg
- Length :46.000cm
- Width :36.000cm
- Height :35.000cm
- Weight :8.500kg
- EAN :
- PackageLength :59.000cm
- PackageWidth :40.000cm
- PackageHeight :35.000cm
- PackageQuantity :1
- With Retail Packaging :No
Product Description
RF4 RF-7050TVD2+4KC1PRO+M156 4K Stereo Microscope Trinocular Zoom 7-50X with 15.6inch HD Display for PCB IC Repair
- 【4K Ultra HD Imaging】Equipped with 4K high-definition camera providing 20MP resolution for capturing detailed images during precise component inspection and electronic repair work.
- 【Trinocular Stereo Design】Features dual eyepiece viewing with an additional camera port, providing comfortable binocular vision for extended use while enabling simultaneous digital recording.
- 【Continuous Zoom 7X-50X】Advanced trinocular zoom functionality allows magnification from 7X to 50X, making it ideal for detailed inspection and repair tasks on PCB circuits and IC chips.
- 【15.6 Inch HD Monitor】Large 15.6-inch high-definition display provides clear and detailed views, enhancing work precision and accuracy for electronic component analysis.
- 【144 LED Ring Light】Integrated 144 LED ring lighting system ensures consistent and bright illumination, improving visibility and reducing eye strain during prolonged use.
- 【Professional Repair Platform】Multi-functional aluminum alloy repair base with positioning holes, grooves, and heat dissipation features specifically designed for mobile phone circuit board maintenance and inspection.
Specifications:
- Model: RF-7050TVD2+4KC1PRO+M156
- Resolution: 4K, 20MP
- Magnification Range: 7X-50X Continuous Zoom
- Eyepiece: WF10X/22mm
- Barlow Lens: 0.5X & 0.7X & 2.0X (Optional)
- Objective: 0.7-5.0X
- Camera Connector: 0.5X CTV
- Head Angle: 45° Tilt, 360° Rotation
- LED Lighting: 144 Adjustable LED Ring Light
- Monitor: 15.6 inch, HD/VGA Input
- Boom Stand: 250mm & φ32mm Column, 300mm × 400mm Base
- Base Material: Multi-functional Aluminum Alloy Repair Platform
Package included:
- 1 x Microscope Camera
- 1 x HD Interface
- 1 x USB Cable
- 1 x English and Chinese User Manual
- 1 x Power Cord
- 1 x Remote Control
- 1 x Microscope Main Unit
- 1 x Display Screen
- 1 x Stand
- 1 x 0.5X CTV
- 1 x 144 LED Light
- 1 x Dust Cover
- 1 x 300x400mm Multi-Function Repair Base
